Onion Bag Potato Mesh Net Bag Machine

Double Needle Bar Raschel Machine

• It is applied for producing bay by slitting machine, reel stand, and raschel machine working with PP/HDPE tapes made from flat yarn making machine. With Max. Working Width: 140” Available for multi-line production to obtain higher output.

Features .

• Yarn feeding from Slitting Machine and creel stand.

• Talking of warp-knitted sacks, the continuous netting is batched into rolls of 1000 mm dia.

durable communication bag

1. Raschel mesh bag machines are suitable for fruit mesh bags, onion bags, etc.
2. All the stitching of the bag is done on the machine. Save the labor cost for the stitching process.
3. Drawstrings can be pulled automatically.
4. The size of the bag is adjustable.

Remark:

1. Special specifications are also available.
2. Manufacturers reserve the right to change the specifications without notice.

Model	SR-140-H-500-A-2
Applicable	PP/ HDPE Flat yarn, Monofilament
Working Width	84” X110” 130” X 170”
Gauge	Per Inch: 2-6-12
Warp Supply Systems	Warping Beams / Slitting Extension Machine /Creel Stand
Performance	400-600 RPM
Number ̥f Bar	6-10 Ground Bars
Power Consumption	7.4KW
Main Motor W/Inverter	7.5 HP

Onion Bag Potato Mesh Bag
